LiFePO4 Battery 24V 400Ah 10.24kWh Leisure Power Storage 25.6V 29.2V

Key Features

• Battery Type: LiFePO4 (Lithium Iron Phosphate)
• Voltage / Capacity: 25.6V rated, 400Ah, 10.24kWh
• Terminal Style: Includes 2 M8 terminals
• Max Charge Voltage: 29.2V
• Discharge Cutoff: 20.0V
• Charge/Discharge Current: Max Charge Current 400A; Max Continuous Discharge 400A; Peak Discharge 800A
• Operating Temperature: Storage 0–59°C; Discharge -20–60°C
• Dimensions (W x H x L): 53 cm x 37 cm x 24 cm (height with terminals 25 cm)

Specifications

• Rated Voltage: 25.6V
• Rated Capacity: 400Ah
• Watt-Hour: 10240Wh (approximately 10kWh)
• Storage & Charging Temp: 0–59°C
• Discharge Range: -20–60°C

Warranty

• Warranty Period: 8 years or 5,000 cycles
• Warranty Benefit: If capacity falls below 80% during warranty, option for full refund or free replacement

Usage & Safety

• Charger Compatibility: Use only chargers designed for LiFePO4 with cutoff not exceeding 29.2V
• Usage Note: Battery should not be fully discharged to extend life
• Temperature Guidance: If ambient temperature is too low, charge in suitable location or add insulation to improve efficiency

What’s Included

• LiFePO4 Battery Module with two M8 terminals

This battery is designed for solar energy storage, emergency power supplies, and other energy storage applications requiring a high-capacity 24V LiFePO4 solution. It does not include a charger.
