AZDelivery KY-024 Linear Magnetic Hall Effect Sensor Module

The AZ-Delivery KY-024 Linear Magnetic Hall Effect Sensor Module is a versatile component for detecting magnetic fields. It features a sensor unit that measures magnetic flux and generates an analog signal. This signal is then amplified by an amplifier, whose gain is adjustable via a potentiometer, allowing for sensitivity control.

A comparator is also integrated, which activates a digital output and an LED when the magnetic signal falls below a set threshold. The module offers two outputs: an Analog Output that provides a direct representation of the sensor's measurement, and a Digital Output that triggers upon detection of a magnetic field.

Please note that the signal at the analog output is inverted; a high magnetic field measurement results in a low voltage output.

Key Features

• Sensor Type: Linear Magnetic Hall Effect
• Module: KY-024
• Brand: AZDelivery
• Outputs: Analog and Digital
• Adjustable Sensitivity: Via onboard potentiometer
• Indicator: Digital output LED
• Compatibility: Arduino and similar microcontrollers
• Included: 3 x KY-024 Modules, E-Book

Technical Specifications

• Signal Inversion: Analog output is inverted
• Onboard Components: Hall effect sensor, amplifier, comparator, potentiometer
