Nema 23 Stepper Motor 1.3Nm 1.8Deg 2.8A 6.35mm Shaft CNC Laser

RTELLIGENT Nema 23 Stepper Motor

This RTELLIGENT Nema 23 stepper motor is designed for precise control and reliable performance in various automation applications. Featuring a 1.8-degree step angle and a holding torque of 1.3Nm (184.12oz-in), it offers accurate positioning and speed control.

Key Features

• Phase: 2 phase
• Step Angle: 1.8 degrees
• Holding Torque: 1.3Nm (184.12oz-in)
• Rated Current: 2.8A
• Wiring: 4-wire
• Shaft Diameter: 6.35mm
• Motor Size: 57x57x76mm
• Characteristics: Low vibration, low noise, low heating, high speed
• Control: Digital motor for accurate position and speed control

Default Connection

The default wire connections are as follows:

• Red: A+
• Blue: A-
• Green: B+
• Black: B-

Applications

This stepper motor is widely used in a variety of applications, including:

• 3D Printers
• Medical Equipment
• Industrial Equipment
• Laser CNC Machines
• Automation Devices
