Hobby Components DS3231 RTC Module for Raspberry Pi - Battery Backup Accurate

Hobby Components DS3231 Real Time Clock Module for Raspberry Pi

This very compact Real Time Clock (RTC) module is based on the highly accurate DS3231 IC and includes a battery backup. The module has a header specifically designed to plug directly into the Raspberry Pi's IO header, requiring no additional wires or soldering. It utilizes the Raspberry Pi's I2C hardware interface to accurately keep the current time and date, even without an internet connection, making it ideal for remote data logging applications.

While specifically designed for the Raspberry Pi, its compatibility with both 3.3V and 5V logic levels allows it to be used with most microcontroller development boards, such as the Arduino.

Key Features

• Item Number: HCRASP0009
• Accuracy: ± 5ppm (± 0.432 sec / day) within -40°C to +85°C temperature range
• Battery Backup: Ensures accurate timekeeping without a power supply
• Low Power Operation
• Controller: DS3231
• Clock Functions: Seconds, minutes, hours, day, date, month, and year timing
• Timing Valid Up To: Year 2100
• Alarms: Two calendar alarms
• Interface: High-speed (400kHz) I2C serial bus
• Supply Voltage: +2.3V to +5.5V

A setup guide for this module is available on the Hobby Components support forum.
