ATEN CS1824 4-Port USB 3.0 HDMI KVM Switch 4K 60Hz Video DynaSync Hub

ATEN CS1824 4-Port USB 3.0 HDMI KVM Switch

Manage four computers with HDMI interfaces from a single USB keyboard, mouse, and HDMI monitor using the ATEN CS1824 KVMP Switch. This KVM switch supports superior video quality up to 4K DCI (4096 x 2160 at 60 Hz) and enhances multitasking efficiency.

Key Features

• Control one USB keyboard/mouse and one HDMI monitor for multiple computers
• Share two USB peripherals across connected computers
• Supports high video quality: 4K UHD (3840 x 2160 at 60Hz) and 4K DCI (4096 x 2160 at 60Hz)
• Video DynaSync technology eliminates startup display issues and optimizes resolution when switching sources
• Integrated 2-Port USB 3.1 Gen 1 Hub with SuperSpeed 5Gbps data transfer rates
• Audio Mixer Modes allow mixing of up to two audio sources for audio output
• Flexible computer selection via push buttons, hotkeys, mouse, and RS-232 commands
• ATEN Standard EDID Mode ensures smooth power-on, high-quality display, and resolution optimization
• Independent switching of KVM, USB peripheral, and stereo audio focus
• HDMI 2.0 compliant and HDCP 2.2 compliant
• Supports HD audio
• On switch detection capability
• Firmware upgradeable

Specifications

• Brand: ATEN
• Model: CS1824
• Ports: 4
• Video Interface: HDMI
• USB Hub Ports: 2 x USB 3.1 Gen 1
• Video Resolution Support: Up to 4K DCI (4096 x 2160 at 60 Hz)
• Data Transfer Rate: Up to 5 Gbps (USB 3.1 Gen 1)
• Compliance: HDMI 2.0, HDCP 2.2

The ATEN CS1824 is an ideal solution for users requiring high-resolution video and efficient management of multiple computers and USB peripherals.
