MikroTik hAP AC Lite Tower RB952Ui-5ac2nd-tc Dual-Band WiFi Router

MikroTik hAP AC Lite Tower RB952Ui-5ac2nd-tc

The MikroTik hAP AC Lite Tower is a dual-concurrent access point providing Wi-Fi coverage for both 2.4 GHz and 5 GHz frequencies simultaneously. Its versatile Universal Case design allows for horizontal (Desktop) or vertical (Tower) positioning, and a wall mounting kit is included.

Key Features

• Dual-chain Wireless: 2.4 GHz (dual-chain) and 5 GHz (single-chain)
• Processor: 650 MHz CPU
• Memory: 64 MB RAM
• Ethernet Ports: Five x 10/100 Mbps Ethernet ports
• PoE Output: Passive PoE output on port 5 (0.5 A)
• USB Port: 1 x USB 2.0 Type A port for 3G/4G modem
• Powering Options: Power jack or passive PoE (8-30 V input voltage)
• Preconfigured: Ready to use out of the box
• Operating System: RouterOS

Specifications

• Product Code: RB952Ui-5ac2nd-tc
• CPU Frequency: 650 MHz
• CPU CORE count: 1
• RAM Size: 64 MB
• Storage Type: FLASH
• Storage Size: 16 MB
• Ethernet Ports: 5 x 10/100 Mbps
• Wireless Bands: 5 GHz radio, 2.4 GHz radio
• Operating Frequency (5 GHz): 5150 – 5875 MHz
• Operating Frequency (2.4 GHz): 2412 – 2484 MHz
• Protocols: 802.11 a/n/ac (5 GHz), 802.11b/g/n (2.4 GHz)
• Chains (5 GHz): Single-chain
• Chains (2.4 GHz): Dual-chain
• Antenna Gain: 2 dBi (2.4 GHz), 1.5 dBi (5 GHz)
• Wireless Chip Model: QCA9887 (5 GHz), QCA9531 (2.4 GHz)
• Antenna Beam Width: 360°
• PoE In: Yes
• PoE Out: Yes (ether5, 0.5 A max)
• Supported Input Voltage: 8 – 30 V (Jack or passive POE)
• USB Port: USB 2.0 Type A, 1 A
• Dimensions: 34 x 119 x 98 mm
• License Level: 4
• Max Power Consumption: 7 W
